1440 Head Engine Lathe
14" Swing Series Geared Head Engine Lathe: Unmatched Power & Precision
The 14" Swing Series Geared Head Engine Lathe offers the perfect combination of high-performance power and precise control, making it the ideal solution for machine shops, tool rooms, and repair facilities. With an impressive 5HP spindle motor and a D1-5 camlock spindle nose, this lathe is designed to handle both small and large jobs with precision, ensuring consistent results every time.
Key Features and Specifications
D1-5 Camlock Spindle Nose: Ensures quick and secure tool changes, reducing downtime and improving efficiency.
8-Step Spindle Speed: Offers a speed range of 70-2000 RPM, suitable for a variety of applications. Upgrade options include:
2-Speed Motor Drive: Expands the range to 16 steps, from 35-2000 RPM.
Variable-Speed Drive: Provides precise speed control from 35-2500 RPM across two variable ranges.
5HP Spindle Motor: Powerful 5HP (3.75 kW) motor delivers smooth, reliable performance across a wide range of operations.
Swing Over Bed: Capable of handling larger parts with a swing over bed of 360mm.
Distance Between Centers: Available in two lengths—750mm or 1000mm—to accommodate different part sizes.
Precision Headstock Gears: Hardened and ground headstock gears ensure durability and smooth operation even under heavy loads.
Induction-Hardened Bed: Built to last, the hardened and precision-ground bed ensures long-term accuracy and resilience.
Built for the Toughest Applications
This lathe is designed for demanding environments where both power and precision are critical. Whether you're working on intricate precision parts or larger, more complex jobs, the 14" Swing Series delivers consistent, repeatable results. The induction-hardened bed ensures durability, while the universal gearbox expands threading versatility for a wide range of machining tasks.
Installation & Setup Process
Stable Placement
Install the lathe on leveling pads provided for stable operation.
Secure Foundation
For best results, ensure installation on a solid concrete slab and anchor the lathe securely to the floor.
Surface Preparation
Remove rust-preventive coatings with WD-40 or a similar solution before initial use.
Precision Leveling
Use two levels to ensure accurate leveling on both the X and Z axes for optimal precision.
Why Choose Willis Machinery?
With over 60 years of expertise in the machinery industry, Willis Machinery is committed to delivering high-quality lathes and metalworking equipment. We provide full support, including parts availability, and customization options tailored to your needs. The 14" Swing Series Geared Head Engine Lathe is built for precision and durability, ensuring it meets the demands of your most challenging projects.
For more details, contact us at sales@willismachinery.com or call 419-537-1717 for customization options and technical support.
